Description
The JustPedals team think the DiMarzio Super Distortion Humbucker Bridge F Spaced Pickup White is a tasty New Distortion Pedals option for your smorgasbord (pedalboard). Just Read More for images videos and latest prices from the DiMarzio brand and delivered by a UK retailer, with warranty & more.
The Super Distortion DP100 has been in the catalogue of DiMarzio in one form or another since the early 70’s and it is still as popular today as it was back then. This high output pickup will kick any clean amp to the edge of crunch and will take a high gain amp up to 11.
This pickup is also incredibly diverse with the ability to be wired to split into series or parallel wiring giving it an incredible amount of variation in tone. Used by artists such as Ace Frehley, Paul Gilbert, Al Di Meola, and Max Cavelera this pickup is everywhere and if you are looking to upgrade your guitar you can’t go wrong with the Super Distortion.
Here’s what DiMarzio say about the Super Distortion Bridge Pickup
Super Distortion
DP100
This pickup started a sound revolution. Replacement pickups simply didn’t exist before the invention of the Super Distortion in the early Seventies. The Super Distortion (and its original 3-conductor version, the Dual Sound) was the first pickup specifically designed to kick a tube amp into total overdrive, and is still the standard by which all other high-output pickups are measured. The Super Distortion has a perfect blend of power and tone: both single-notes and chords jump out of the amp and fill the room (or the track) with a wall of sound. The balance of tones is classic – thick, boosted mids, big lows and fat highs. This is the sound you’ve heard for over three decades on platinum records, from players as varied as Ace Frehley, Al Di Meola, and Paul Gilbert. It’s also versatile: 4-conductor wiring allows instant access to Strat-like split and series-parallel modes. Discover what thousands of great players know: the Super Distortion is the best all ’round high-power pickup ever made.
Recommended For
The Super Distortion is primarily a bridge position pickup, although it can be used in the neck position with a relatively low-gain amp. Specifically designed for solid-bodies: hollow and semi-hollow guitars can be hard to control with warm, high output pickups.
Tech Talk
When we first built the Super Distortion, it was a 1-conductor pickup. As a 4-conductor pickup, it’s extremely versatile. Coil-splitting produces a very Strat-like option, both in tone and power. Parallel wiring is similar to splitting, but it’s still humbucking and a little more hollow-sounding; Paul Gilbert used to use two Super Distortion pickups wired in parallel when he was in Racer X.
Specifications
- Wiring: 4 Conductor
- Magnet: Ceramic
- Output mV: 425
- DC Resistance: 13.68 Kohm
- Year of Introduction: 1972
- Patent: n/a
