Do you want to send a line signal – stereo or dual mono – to multiple devices, without interference such as hum? Then the Palmer /Peene line splitter box is the right tool for you. It works on a purely passive basis with large isolation transformers, which can even handle high-level signals without distortion. So, for instance, you can send the stereo output signal from the mixer to several power amps, without any ground loops. The Palmer Peene also includes a ground-lift switch. In addition to the two transformer-isolated outputs, the Peene also directs the input signal on directly via a link out.
The Palmer Peene is everything you need to distribute line signals to several devices and is a reliable audio tool with ultra-simple handling and professional sound characteristics.
Key Features:
- Solid casing made of aluminium and steel:
– Study and hardwearing, built to stand the test of time… and musicians. - Extremely fail-safe, no power supply required:
– One less failure point, making sure there’s less to go wrong for the show. - Two inputs split to two outputs each
– Sometimes you just need to split a signal, this could be for many reasons including recording a live set, this is exactly that!
Specifications:
- Type: Passive
- Channels: 2
- Inputs:
– Number: 2
– Type: Unbalanced
– Connector: XLR - Outputs:
– Number: 4
– Type: Balanced
– Connector: XLR - THRU outputs per channel: 1
- Dimensions:
– Width: 50mm / 1.97“
– Length: 128mm / 5.04“
– Height: 140mm / 5.51“
– Weight: 805g / 1.77lbs
