Add “Soul” to your sound by producing creamy boost and overdriven tones that enhance harmonics while maintaining the transparency of your guitar tone. The pedal is equipped with incredibly flexible tone shaping options to help customize your sound.
Enhance The Tonal Spectrum Transparently
The “Mid boost” knob pushes the mid-range frequencies creating rich dynamics and the “Tone” knob (not just your ordinary tonecircuit) can be set from a super tight bottom end to “in your face” highs. Soul Driven will help you dial in the “sweet spot” every time.
Need More Headroom? You Got It!
The Xotic “Voltage Doubler” is a step-up converter that takes 9 volts DC and boosts it to an output voltage of 15 or 18 VDC (max current draw 80mA).
Why do you need a voltage doubler? Higher voltage levels result in more headroom. When you boost the voltage your find your Xotic pedals will get much more dynamic, more headroom, top end and brightness, less compressed sound.
Specifications
- Dimensions (W/D/H): 4.39″ x 2.38″ x 1.98″ (110mm X 60mm X 50mm)
- Weight: 0.68 lbs. (309g)
- Bypass: True Bypass Switching
- Power Consumption: 9VDC/4mA or 18VDC/6mABattery Type: 9VDC (006P) x 1
- AC Adapter (Optional): 9VDC-18VDC, Negative Tips (Regulated recommended)
- Input Impedance: 500k ohm (min)
- Output Impedance: 10k ohm
