TPS-10 is a high-quality multi-output all isolated pedal power supply.
It is from the brand new TONECITY TPS series 2024, it is designed based on brand new all isolation technology, each output is truly electrically isolated. It has super carrying load capacity and Dual short-circuit protection function system.
Key Features
- Superior load capacity and low interference and noise – High performance circuit design with dual stage filtering combined with UHS IC for automatic voltage compensation function. Highly energy efficient power conversion with extremely low loss. A stable voltage also ensures a stable sound, as the headroom of distortions, overdrive pedals etc. remains stable. All for a great playing experience!
- Low heat dissipation – The efficient circuitry means that extremely little energy is converted into heat.
As a result, the power supply heats up very little, ensuring a long service life.
This series is the ideal choice for users looking for a reliable and safe power supply with many outputs and low heat dissipation. - Low weight – Very thin body construction, lightweight so you can easily keep it on your board and carry it anywhere.
Dual short circuit protection systems.
A short-circuit protection circuit design for each output. An IC with short-circuit protection function for each output. When any single or more output occurs short circuit, output will be quickly cut off, corresponding red LED light will be off to help users quickly find out fault points. When the fault is eliminated, the red LED light will be on. Along with this process, the other output will not be affected. These ensure the safety of the music equipment and the stability of the playing.
Specifications
- Input: DC12V/3A（DC adapter）
- Outputs：DC9V/500mA *2, DC9V/200mA *4, DC6/9V-200mA *1 (switch on to get DC 9V), DC9/12V-200mA *1 (switch on to get DC 12V), DC9/15V-200mA *1 (switch on to get DC 15V), DC9/18V-200mA *1 (switch on to get DC 18V), USB Charger 5V/1A *1
